MY-D019D-N

Portable X Ray Machine D019D-N

Portable X Ray Machine D019D-N

MY-D019D-N

Portable X-ray machine

You have any question?

MY-D019D-N Information

Portable X-ray machine

MY-D019D-N Parameter

Output Power	5.3kW
Rated Voltage	220VAC ,±10%, 50/60Hz
Inverter Frequency	100kHz /- 5%
kV accuracy	4%
mA accuracy	≤±(5%) (mA≥25mA, ms>5);≤±(10% +1mA) (mA≤25mA);
Rotor	Fixed Rotor
kV Range	40kV-125kV, 1kV step
mA Range	10-100mA (R^20)
ms Range	1-4000ms (R^20)
ms accuracy	≤±(5% 0.2ms)
mAs Range	0.1-200mAs (R^20)
mAs accuracy	≤±(5%0.2mAs)
Tech. mode	kV-mAs;kV-mA-ms
APR num	2000
Communication Interface	RS-232
Volume	450255220 (include collimator)
Weight	15kg
